Technical Data Sheet
Material Composition:
Factors affecting gasket Application Areas The suitability of gasket materials for use depends on a large number of factors as shown in the above drilling. Max. temperature and pressure values cannot determine suitability for the application. It is always advisable to consider these factors when selecting a particular material. This area indicates that the gasket material is usually suitable for chemical compatibility. This area indicates that the gasket material may be suitable but
Super Light 5000
Asbestos Chrysotile Fibers, Mineral Fibers, Natural Rubber and NBR.
General Properties and Applications:
For sealing of water, steam, air and alkaline chemicals for low stress conditions.
Standard Sheet Dimensions:
1500 x 4000 mm, 1500 x 2000 mm, 1300 x 3900 mm, 1270 x 1270 mm, 2100 x 3000 mm, 1500 x 3000 mm.
Specifications: IS 2712:1998 Grade: W/3
Compatibility: ASTM: F104 F 112000 M4
Finish: Red/Fanta, Red, Black, Blue, GRN.
(Other color on customer requirement).
Specified Value
Max. Operating Temperature 380
Max. Operating Pressure 35
Density 1.7 -2.20
Compression 6-14
Recovery ≥ 40.0
Tensile Strength ≥ 6.7
Loss on Ignition ≤ 28
Flexibility No Cracks All information and recommendations given in this booklet are correct to the best of our knowledge. However, in view of the wide range of possible installation and operating conditions one cannot draw a final conclusion in all application cases regarding the behavior in a joint gasket. Therefore, the information can only serve as a guide.
ASTM F 152 N/mm²
ASTM F 495%
ASTM F 147 B –
ASTM F 36 A%
This area indicates, Do not install gasket without technical evaluation.
Standard sheet sizes: 1500 x 1500 mm, 1500 x 2250 mm, 1500 x 4500 mm, 1500 x 1000 mm, 1000X1000 mm
The following information applies to material thickness 1.5 mm. Test Method Unit
°C
Bar
ASTM F 1315 g/cm³
ASTM F 36 A%
Consider these factors when selecting a material for a particular application.
This area indicates that gasket material may be suitable but technical support is recommended.
